TEMPSENS · TMC12

Single Diaphragm Differential Pressure Gauge

Name: Single Diaphragm Differential Pressure Gauge
Brand: TEMPSENS
SKU: TMC12

Temperature range: 10…150°C max.

Category: Industrial sensors · Differential pressure gauges

Specifications by model

Characteristic	Value
Généralités	General
Conception	EN 837-3
Tolérance	±1.6% of full scale
Température ambiante	-40…+65°C [without dampening liquid] -20…+65°C [with dampening liquid]
Température de service	10…150°C max.
Limites de pression	Steady pressure up to FS value Fluctuating pressure up to 90% of FS value Short time 1.3 x FS value for range up to 100 bar Short time 1.15 x FS value for range above 100 bar
Soudures	TIG argon arc welding
Version standard	Standard Version
Diamètre du cadran	DN100 / DN125 / DN150
Étendue	25 mbar…0...25 bar
Montage	Direct, Bottom connection
Raccord process	¼" NPT (F) x 2 Nos.
Indice de protection	IP 65
Exécution	Dry / Dry but fillable
Matériau	Material of construction
Élément sensible	Diaphragm
Matériau du boîtier et de la lunette	AISI 304 SS [Bayonet type]
Diaphragm, Bourdon tube & Shank	AISI 316L SS
Mécanisme	AISI 304 SS
Cadran	Aluminum, black graduation on white background
Aiguille	Fixed, aluminum, black powder coated
Joints	Neoprene
Hublot	Plexi glass
Versions remplies	Filled versions
Glycérine	Glycerin
Tolérance	±4.0% of full scale
Liquide amortisseur	Glycerin 99.7%
Electric Contact version	Electric Contact version
Tolérance	±4.0% of full scale
Hublot	Poly carbonate dome
Contact	1NO; Make contact
Liquide amortisseur	Dielectric oil [Optional]
Effet de la température	When temperature of the measuring system deviates from reference temperature (+20°C) : max error ±0.4% / 10K of true scale value.

• All SS measuring system • External Zero adjustment • Electric contact version • Dry / liquid filled
